JS750 Concrete Mixers
  • Condition:New
  • Delivery port:Qingdao or Tianjin port, China
  • Payment term:L/C, T/T
  • Guarantee period:12 months
  • Delivery time:10-15 days after received deposit
  • Installation time:20days
We're here to help: (� Click this button to inquiry)Easy ways to get the answers you need.

1. Stir well

The agitating blades of the circular grooved mixing cylinder are staggered so that the mixture is fully stirred in the cylinder and the mixture is quickly and uniformly stirred.

2. Compact structure

Changli 750 concrete mixer unloading door driven by imported hydraulic system, compared with the traditional form of drive, with a compact, stable operation, accurate positioning and other characteristics of the door.

3. Beautiful appearance

Changli 750-type mixer using the classic yellow as the product of color, noble and stable.

4. Sealing is good

750 mixer with three seals and aggregate frame seal and hydraulic system for the pump, which can effectively prevent the main neck shaft was rapid wear and tear caused by slurry leakage phenomenon.

5. The cycle time is short

General mixer blade speed 26 r / min, JS750 mixer speed of 29.3 r / min.

6. Easy to operate

750 blender, whether it is feeding, unloading, or water supply, are highly automated, and all of the motor control parts are in the electric box, the use of safe, reliable, easy operation and maintenance.

When the material feeding system, will need to mix the mixture in the hopper, the start feeding system, wire rope hopper to climb up, climb to a certain height, the hopper into the rack, Doumen automatically open, Into the mixing tube.

JS750 mixing system by the motor, pulley, gear box, gear, mixing device, mixing tube and other components. The main motor through the belt connected to the two-stage gear box, and finally through the two pairs of open gears were driven two horizontal configuration of the mixing shaft rotating at constant speed.

Electrical control system need to control the JS750 concrete mixer of the main drive motor, water supply system motor, feeding, cutting and other motor. All electrical control elements are located in the distribution box. The electrical components in the distribution box are mounted on an iron plate for safe and reliable operation and easy maintenance.

Discharging system In the bottom of the mixer, through the manual putter to implement discharge. According to customer requirements, you can produce electric putter discharge form of the mixer. The connection between the discharge gate and the mixing cylinder is sealed with the sealing plate, and the position of the sealing plate can be adjusted to ensure the purpose of sealing.

JS serial double horizontal shaft compulsion type concrete mixer is a multi-function mixer,our JS series concrete mixers are widely used as the mixer in concrete plant to produce commercial concrete.This mixer has characteristics of simple structure,high mixing quality,high efficiency,energy-saving,low noise,simple operation,and can be used together with dump car,truck and concrete mixing truck,its the ideal machine of construction sites,large and medium-sized concrete factories.
